How to auto sample a VST3i on windows?

Discussion in 'Samplers, Synthesizers' started by ArticStorm, Mar 25, 2022.

  1. ArticStorm

    ArticStorm Moderator Staff Member

    Joined:
    Jun 7, 2011
    Messages:
    7,835
    Likes Received:
    4,015
    Location:
    AudioSexPro
    Hey there,

    i am using Extreme Sample converter to auto sample, but this seems to work only well with VST2 x64 bridge via jbridge into ESC. I am on windows, i know MacOS has a good solution there, but for windows there seems to be none, which is uptodate and which also selts you export sf2 or other variants.

    So far i have tried:
    1. VST3 64 -*-> Patchwork 2.5.1 VST2 64 --> jbridge -**-> ESC

    * patchwork eats only same bit versions. :(
    ** ESC supports only 32bit VST2 :(:(

    Looks like Rolands TR VST3 plugins can get any MIDI signals from the DAW/ESC and therefore you cant record anything. With the VST3 variantes of the Synths it just works.

    2. VST2 64 --> jbridge --> ESC works just fine.

    3a. MPC Beats supports on VST2 64, no VST3!

    3b. VST3 64 --> Patchwork VST2 64bit --> MPC Beats, but should have the same problem, bcs Roland fucked up.

    4. Any other ideas?

    Thinks to try:
    Chickensys Translator?
    Samplerobot?
    Samplit?

  2.
  3. BEAT16

    BEAT16 Audiosexual

    Joined:
    May 24, 2012
    Messages:
    9,081
    Likes Received:
    7,009
    TX16Wx Software Sampler - Sampler/Sample Player Plugin by CWITEC

    TX16Wx Software Sampler by CWITEC is a Virtual Instrument Audio Plugin for macOS and Windows.
    It functions as a VST Plugin, an Audio Units Plugin, a VST 3 Plugin and an AAX Plugin.

    www.tx16wx.com

  4. ArticStorm

    ArticStorm Moderator Staff Member

    Joined:
    Jun 7, 2011
    Messages:
    7,835
    Likes Received:
    4,015
    Location:
    AudioSexPro
    Other idea: Samplit v2 Free supports VSt64, so could use Polac VST3 shell, but its not seeing plugins right now.
    Free version lets you sample 3octaves (you can move the 3 octaves around.)

    @BEAT16 but it cant autosample a VST instrument. Its only a sampler.

  5. BEAT16

    BEAT16 Audiosexual

    Joined:
    May 24, 2012
    Messages:
    9,081
    Likes Received:
    7,009
    Ohhh.... sorry...!

    Direct Wave by Image Line which can sample VST instruments - www.image-line.com/fl-studio/plugins/directwave
    XtractpleR - A Multi-Velocity Audio Sample Extractor - www.xtractpler.com
    SampleRobot - www.samplerobot.com/

    Newsonicarts Freestyle www.newsonicarts.com/html/freestyle.php
    DiscoDSP's Bliss: www.discodsp.com/bliss/

    Translatorâ„¢ 7 - Professional Instrument Conversion Software
    www.chickensys.com/products2/translator/formats.html

    Last edited: Mar 25, 2022
  6. ArticStorm

    ArticStorm Moderator Staff Member

    Joined:
    Jun 7, 2011
    Messages:
    7,835
    Likes Received:
    4,015
    Location:
    AudioSexPro
    The main problem is that none of these autosampler seem to support VST3 native. only vst2.

    trying wrappers now.

  7. BEAT16

    BEAT16 Audiosexual

    Joined:
    May 24, 2012
    Messages:
    9,081
    Likes Received:
    7,009
    This is really bad news ! Is he not the right one ? 99 euros: DiscoDSP's Bliss: www.discodsp.com/bliss/

    [​IMG]


  8. ArticStorm

    ArticStorm Moderator Staff Member

    Joined:
    Jun 7, 2011
    Messages:
    7,835
    Likes Received:
    4,015
    Location:
    AudioSexPro
    same problem, TRxxx plugins stay silent, guess its due to their multi channel routing?

    Bliss demo works fine, if only Rolands plugins would work :deep_facepalm: like they should ...

  9. BEAT16

    BEAT16 Audiosexual

    Joined:
    May 24, 2012
    Messages:
    9,081
    Likes Received:
    7,009
    It's been a long rocky road, but it's good to hear that the Bliss is working.

  10. ArticStorm

    ArticStorm Moderator Staff Member

    Joined:
    Jun 7, 2011
    Messages:
    7,835
    Likes Received:
    4,015
    Location:
    AudioSexPro
    i will just manual sample it now and then edit with audio editor.

    I have tried so much yet and everything kinda fails at some point ...

    i tried the following:
    Tr707 --> Metaplugin (works fine in ableton) ---> Samplit v2 demo
    crashed or i cant get it to sample anything?
    But i know in ableton it was reacting to midi messages.

    TR707 --> Blisss, again nothing is sampled, since roland drum machines, seem to lock or the audio Outs are weird.

    Other idea:
    TR707 --> Metaplugin 32 --> ESC, well here ESC says - its not a valid VST plugin :woot: Maybe to many outputs? it has 32 mono outputs.

    i gave up on polacs vst3 shell since it just doesnt generate any vst2 version of vst3 plugins, i have read the readme, googled, tried combinations.

    And all due Steinberg forcing VST3 on everybody. For the most purposes VST2 just works fine.
    Remember TR909 VST2 just works fine in PW and everywhere, but the same VST3 just doesnt work :dunno::deep_facepalm:

  11. Xupito

    Xupito Audiosexual

    Joined:
    Jan 21, 2012
    Messages:
    7,291
    Likes Received:
    4,027
    Location:
    Europe
    I guess you could do it writing an extension for Reaper. Extension, not plugin.
    But of course, that sounds like a lot of pain.

    • Interesting Interesting x 1
    • List
  12. ArticStorm

    ArticStorm Moderator Staff Member

    Joined:
    Jun 7, 2011
    Messages:
    7,835
    Likes Received:
    4,015
    Location:
    AudioSexPro
    probably, but by that i had sampled all Roland drum machines from the cloud.

    for hardware and other softsynths ESC works fine.

  13. Moonlight

    Moonlight Audiosexual

    Joined:
    Jun 12, 2011
    Messages:
    2,467
    Likes Received:
    762
    Location:
    Earth
    imo, best autosampler is built into apple logic. Its penrose looper sounds perfect.
    It creates EXS patches, which can be read with other synths/sampler or converted etc <3
    DiscoDSP Bliss also can autosampler VST even offline bounce ! but it's loops sound um well ...

  14. alex921

    alex921 Producer

    Joined:
    Jan 27, 2016
    Messages:
    282
    Likes Received:
    120
    FxPansion Geist 1 and 2

  15. Djord Emer

    Djord Emer Audiosexual

    Joined:
    Sep 12, 2021
    Messages:
    981
    Likes Received:
    801
    are you planning to sample in bulk? because you can always just ...render the midi to audio in any daw

    also, check for Redux, I know Renoise has native VSTi sampling so perhaps Redux has the same function.

  16. alexbart

    alexbart Producer

    Joined:
    Mar 17, 2013
    Messages:
    146
    Likes Received:
    98
    Have you considered of using the hardware sampling mode from tools like Extreme Sample Converter or Sample Robot or similar software?
    If you are able to do some routing between the VST3 you want to sample and the sampling utility, then you can sample it like it is real hardware in real time.
    You could use the Rearoute driver with Reaper to take advantage of the routing between different applications, such as Reaper will load the VST3 to be sampled into Extreme Sample Converter and will be set to send the audio to Rearoute 1/2 and Extreme Sample Converter will get the audio from Rearoute 1/2, it will start the automated sampling process in real-time without any problems, I have done it several times.

    • Interesting Interesting x 2
    • Agree Agree x 1
    • List
  17. clone

    clone Audiosexual

    Joined:
    Feb 5, 2021
    Messages:
    7,540
    Likes Received:
    3,323
    Logic Autosampler is my favorite way, by far. SampleRobot used to be great for hardware, but its very expensive and no scene releases in forever. it definitely works great, for plugins too :)

    Last edited: Mar 26, 2022
  18. ArticStorm

    ArticStorm Moderator Staff Member

    Joined:
    Jun 7, 2011
    Messages:
    7,835
    Likes Received:
    4,015
    Location:
    AudioSexPro
    sounds interesting.

    Can you write me a detailed tutorial how to set it up? (I am a reaper beginner, know very very little about reaper)

    Thanks.

  19. ArticStorm

    ArticStorm Moderator Staff Member

    Joined:
    Jun 7, 2011
    Messages:
    7,835
    Likes Received:
    4,015
    Location:
    AudioSexPro
    Yes i heard about logic autosampler. To bad there is nothing good working for the windows side.

    The price for Sample Robot is insane, also sampleit (has only vst2 support) with 140$$$, damn.

    Well actual i wanted to create some samples of the Roland TR plugins (808,909 i can do, since they are still VST2!), but the newer ones TR606, TR707, TR727 do not work since they are VST3 only. If you want to create me some?

    I want them in variants
    - clean
    - dirty (volume a bit driven to max)
    - different decay variants ofc, sometimes one can create cool sounds out of the tails - decay parts of the hats for example.

    I have tried Bliss, it was not working with Rolands VST3's, i tried everything for 2 hours ...

    maybe in the future for other VST3 plugins.

    Last version i found was 3.2.1, which doesnt have VST3 support and well i have never used Renoise, so learning curve would be very stiff to maybe in the end find not a way to autosample VST3 plugins.

  20. Oneeyedstan

    Oneeyedstan Platinum Record

    Joined:
    Nov 11, 2021
    Messages:
    414
    Likes Received:
    227
    Location:
    Vienna
    This should be easy possible with blue cats patchwork...

  21. ArticStorm

    ArticStorm Moderator Staff Member

    Joined:
    Jun 7, 2011
    Messages:
    7,835
    Likes Received:
    4,015
    Location:
    AudioSexPro
    Patchwork does not work with VST3 plugins by roland as i wrote above in the first starting post. i was not able to trigger MIDI from outside of patchwork with TR707 inside of patchwork.
